Superbat BNC Female Solder Connector 4 Hole Flange Panel Chassis Mount 50ohm Coax Connector for Module, Test/PC/LAN Board, Spectrum/Network Analyzer, Secyrity Camera 5Pcs

• Connector Type:BNC Female(5Pcs); Color:Silver; Material:Nickel-plated brass; Termination Type:Terminal; Mount Method:4 Hole Flange; Attachment Method:Solder; Dielectric Type:PTFE; Frequency Range:3GHz; Impedance:50 ohm,Low-loss.
• Feature:Made of nickel-plated brass,it ensures high-speed and stable signal transmission while providing excellent corrosion resistance.It is easy to install and disassemble,bayonet connection method ensures a secure and firm connection without falling off easily.With excellent vibration resistance and a lifespan exceeding one thousand cycles,ensuring mechanical durability.
• Application:For Monitor, Broadcast, Telecom, Test Board, PC/LAN Board, Cable Modem, Amateur Radio Transceiver and Amplifier, Medical/Test Equipment, RF Applications etc. It is easy to install and disassemble.Before you buy,please confirm whether the connector supports your device.
• Package:5Pcs BNC female 4 Hole flange panel chassis mount connectors.
• Never worry about any product safety issues. We are confident in the quality of our BNC connectors and are willing to offer 1 Month replacement warranty. If you unfortunately get a defective one, please seek assistance from customer service.

Superbat BNC Connectors 50ohm BNC female flange PCB board welding joint Description: Connector Type：bnc female, plug Impedance: 50ohm BNC female 4 hole flange terminal connector has an interface type of solder cup and a 50 Ohm impedance. BNC female 4 hole flange connector uses shield/contact solder as an attachment method. Our male BNC terminal connector provides a minimum frequency of DC and a maximum frequency of 3 GHz. The BNC female 4 hole flange terminal connector has a PTFE dielectric type and a VSWR of 1.3. The BNC terminal connector has a brass body with nickel plating. Our BNC connector uses brass contact. BNC 4 Hole panel Flange Mount with solder cup straight RF Coax connector Application: These bnc connectors are easy to solder to a proto board, test boards, PCB antennae, modules, Broadcast , RF Applications, PC/LAN board, amateur radio transceivers and amplifiers,Cable Modems etc.
