HELUKABEL 29104 Wire Cables H05 V-K Ring 1 x 0.75 mm²

• Single core/wire cables PVC
• Strands fine-stranded class 5
• Braids blank

Technical data: PVC single cores according to DIN VDE 0285-525-2-31 / DIN EN 50525-2-31 and IEC 60227-3. Temperature range moved -5°C to +70°C not moved -30°C to +80°C. Rated voltage U0/U 300/500 V. Test. 20000 V ● Insulation resistance min. 10 MOhm x km ● Minimum bending radius fixed 4 x core diameter ● Radiation resistance up to 80 x 106 cJ/kg (up to 80 Mrad) construction ● Copper wire blank, according to DIN VDE 0295 class 5, fine-stranded, BS 6360 cl.5, IEC 60228 cl.5. ● Wire Insulation made of PVC, mix type TI1 according to DIN VDE 0207-363-3 / DIN EN 50363-3 and IEC 60227-3. Wire marking see table below. Features: The materials used in production are silicone- and cadmium-free and free from substances that interfere with paint wetting. Tests. PVC self-sealed. and flame-extextextextrig according to DIN VDE 0482-332-1-2, DIN EN 60332-1-2, IEC 60332-1 (complies with DIN VDE 0472 part 804 test type B)
