Waveshare SIM7600G-H 4G HAT, Supports LTE Cat-4 4G/3G/2G, GNSS Positioning, Global Band, Compatible with Raspberry Pi 4B/3B+/3A+/3B/2B/1B+/1A+/Zero 2 W/Zero W/Zero/Jetson

• Standard Raspberry Pi 40PIN GPIO extension header, supports Raspberry Pi series boards, Jetson Nano.
• Supports dial-up, telephone call, SMS, TCP, UDP, DTMF, HTTP, FTP, etc. Supports GPS, BeiDou, Glonass, GALILEO, QZSS, LBS base station positioning
• Onboard USB interface, to test AT Commands, get GPS positioning data, and so on. Onboard USB to UART converter, for serial debugging
• Onboard audio jack and audio decoder for making telephone call. 2x LED indicators, easy to monitor the operating status. Onboard voltage translator, operating voltage can be configured to 3.3V or 5V via jumper.
• Comes with development resources and manual (examples for Raspberry Pi/Jetson Nano/STM32).

Features Standard Raspberry Pi 40PIN GPIO extension header, supports Raspberry Pi series boards, Jetson Nano Supports dial-up, telephone call, SMS, TCP, UDP, DTMF, HTTP, FTP, etc. Supports GPS, BeiDou, Glonass, GALILEO, QZSS, LBS base station positioning Onboard USB interface, to test AT Commands, get GPS positioning data, and so on Onboard USB to UART converter, for serial debugging Breakout UART control pins, to connect with host boards like STM32 SIM card slot, supports 1.8V/3V SIM card TF card slot for storing data like files, messages, etc. Onboard audio jack and audio decoder for making telephone call 2x LED indicators, easy to monitor the operating status Onboard voltage translator, operating voltage can be configured to 3.3V or 5V via jumper Baudrate: 300bps ~ 4Mbps (default: 115200bps) Autobauding baudrate: 9600bps ~ 115200bps Control via AT commands (3GPP TS 27.007, 27.005, and V.25TER command set) Supports SIM application toolkit: SAT Class 3, GSM 11.14 Release 99, USAT Comes with development resources and manual (examples for Raspberry Pi/Jetson Nano/STM32). User Manual waveshare.com/wiki/SIM7600E-H_4G_HAT?amazon Support If you require technical support, please go to the Support page in the wiki and open a tickets.
