Seaflo 12V 1.2 GPM 35 PSI Water Pressure Diaphragm Pump

• Able to supply water to two taps. 2 years warranty.
• 18AWG,13" long Leads. 10mm (3/8") Hose barb connections.
• Ignition protected.
• Meets or exceeds RoHS, SGS, and ISO standards.
• Industry standard mounting pattern. Intermittent duty.

The 21-Series Pumps are compact and designed for a wide range of applications including liquid transfer, spraying, circulation, filtration and dispensing. The 21-series of diaphragm pumps are self-priming and can be run dry without harm. It provides up to 1.2 gallons per minute. Miniature multi outlet water pressure pump serves 1 or 2 3/8” (10 mm) outlets at any one time. This compact automatic demand water system pump has a built-in pressure switch, which automatically starts and stops the pump when faucet is opened and closed. TYPICAL APPLICATIONS Marine, RV, Agricutural Spraying, General Industial, Filtration, Beverage Processing, Solar Water System. INFORMATION Type:2 Chamber positive displacement diaphragm pump, self priming, capable of being run dry Control Type:Pressure switch Max Recommended Temperature:60° C (140° F) Priming Capabilities:4 feet (1.2 m) suction lift Re-start Pressure Shut-off Pressure 35 PSI: 25 PSI ±5 PSI (±0.3 bar) Inlet/Outlet Ports:3/8" (10 mm) hose barb Weight:1.3 lbs (0.6 kg) MOTOR Leads:18 AWG, 14" (35 cm) long with 2-Pin connector / Leads Duty Cycle:Intermittent Max.Amp Draw:4.0 A Fuse:6.0 A STANDARD PUMP CONFIGURATIONS Voltage:12V Open Flow（GPM/LPM）:1.2 / 4.3 Max Draw:4.0A Shut-off Pressure（PSI/BAR):35 / 2.4 Valves:EPDM Diaphragm:Santoprene
