Remote Control Module, 2 Channel IP Network Relay Switch Module, Reliable for Motor Electric Light

• 【MULTI-SUPPORT】The network controller support working in TCP server, TCP client and UDP mode. Working in TCP server mode supports 4 client connections. Support for MODBUS TCP protocol, support for KingView. Support online update program, very convenient for customers to customize the program.
• 【CUSTOMIZABLE】IP network relay module can customize the device name, support Chinese definition, do not need to record tedious IP when there are many devices. User-defined heartbeat packet time, reliable network recovery.
• 【HIGH PERFORMANCE】This network controller a 32-bit single-chip microcomputer with a high-performance for Cortex-M3 core is used, and the network chip is a W5500 with a hardware protocol, which is high temperature resistant and can work in an environment of -40 degrees to +85 degrees.
• 【REMOTE CONTROL】Ip network relay switch module provide host computer C ++ source code, reliable network connection, router restart after disconnection, reliable network connection recovery, remote control across gateways.
• 【APPLICATIONS】2-channel 10A relay controllers, with normally open output without normally closed output, can be used for smart home control, and can be used to remotely control electric lights, motors, and other electrical equipment using mobile phones or computers for secondary development.

Feature: 1. Support working in TCP server, TCP client and UDP mode 2. Working in TCP server mode supports 4 client connections. Support for MODBUS TCP protocol, support for KingView 3. Support online update program, very convenient for customers to customize the program 4. Can customize the device name, support Chinese definition, do not need to record tedious IP when there are many devices 5. User-defined heartbeat packet time, reliable recovery Specification: Item Type: IP Relay Module Supply Voltage: 5V Current: Not less than 1A Two-channel relays can a single function rate of 2KW, AC load rated voltage 250V, current 10A, DC load rated voltage 30V, current 5A Size: Approx. 81 x 50 x 31mm / 3.2 x 2 x 1.2in Operating Temperature: -40℃ to 80℃. Applications: 1.Can be used for smart home control, control router restart after disconnection, etc. 2. It can remotely control electric light, motor, and other electric equipment using mobile phones or computers for secondary development. 3. Can be used for power failure detection in the computer room, can be connected to human body infrared sensors, can be connected to key switches, can be connected to smoke alarm output. 4. Can be used for access control, computer control, remote control of electrical appliances 5. Can be connected to smoke alarm output, can be connected to human body infrared output 6. Can be connected to key switch, can be connected to any passive switching input, can also be connected to active switching input (connected to 5V active switching). 7. Can be controlled by external network, and can be controlled remotely by mobile phone. Control Instruction: Send: on1 turns on the first relay Se
