RASMACOR | Modular Multifunction Timer | Carlos Gavazzi DMB51CM24 | 7 Functions and 7 Time Ranges | Multifunction Power Relay 24VDC and 24VAC at 240VAC | Time Range 0.1s to 100h

The DMB51CM24 is a multifunction timer with 7 functions and 7 selectable time ranges with the controller between 0.1s and 100h. The period starts as soon as the trigger contact is closed. At the end of the set delay period, the relay operates and does not turn off until the trigger contact is closed again or power is turned off. If the trigger contact is closed before the delay time ends, the device restarts and a new period begins. The relay operates and the period starts as soon as the trigger contact is closed. The relay is turned off at the end of this period or when the power is turned off. The relay works again when the trigger contact closes again. If the trigger contact is closed before the delay time ends, the device restarts and a new period begins. Selectable time range from 0.1s to 100h Auto or Manual start 0.2% Repeatability SPDT Contact Setup Combined AC and DC Power Supply LED Indication for Relay Status and Connected Power Supply (ON) Wide power range from 24VDC and 24VAC to 240VAC
