Six Microphone and 2 Line Level Mixer

• 6 switchable mic or line inputs
• 2 stereo aux inputs
• Individually switchable phantom power
• 24Vdc power option

Product Description 1U Mic/Line Rack Mixer Rack-mountable 1U mixer with 6 mic/line inputs and 2 auxiliary inputs. Each mic/line channel has switchable phantom power and input level. Output connections are stereo XLR, mono jack or REC output on RCA with master bass and treble tone controls. Designed as a master or expansion mixer for installed sound systems and conferences. PRODUCT FEATURES: ★ 6 switchable mic or line inputs ★ 2 stereo aux inputs ★ Individually switchable phantom power ★ 24Vdc power option SPECIFICATION: ★ Power supply 100-240Vac, 50/60Hz (IEC) or 24Vdc (terminals) ★ Fuse T1AL 250V (mains) or F500mA (24Vdc) ★ Phantom power +20Vdc (switchable) ★ Inputs : mic/line 6 x balanced XLR ★ Inputs : aux 2 x L+R RCA ★ Outputs L+R XLR, mono 6.3mm jack, L+R RCA (REC) ★ Controls 6 x Mic/Line level, 2 x Aux level, Treble, Bass, Master ★ Input impedance 3.3k Ohms (mic/line), 10k Ohms (aux) ★ Frequency response : mic 20Hz - 18kHz ★ Frequency response : line 14Hz - 20kHz ★ Frequency response : aux 10Hz - 23kHz ★ Input sensitivity : mic -45dBV ★ Input sensitivity : aux/line -10dBV ★ Signal to noise ratio : mic 55dB ★ Signal to noise ratio : aux/line 60dB ★ THD 0.05% ★ Dimensions 482 x 130 x 44mm ★ Weight 1.43kg Box Contains 1 x Rack Mixer
