Qiilu Infrared Beam Sensor, Active Infrared Beam Sensor Anti Theft for Gate Openers Access Control Security Alarm System

• Multiple applications ------ Active infrared barrier sensors are widely used in the door system, access control system, security alarm system, etc. Perfect match, is a high-performance accessory to help you better upgrade performance
• Function ------ Infrared barrier alerts can enhance the ability of the detector to resist RFI or EMI, protection, etc., and adapt to harsh environments. Please confirm before buying, avoid buying errors, improve the shopping experience
• The receiver range ------ The receiver receives less than or equal to 15 m / 49.2 feet, when there is a harsh weather (such as heavy rain or fog), the distance will be shortened by 30%. Easy to maintain reduced your replacement cost
• Size ------ The size is about 100x35x40mm/3.94x1.38x1.57in, the wavelength is 940nm, and the input power is DC or AC 12-24V. Infrared barrier detectors are anti -theft, alarm, safety equipment and channel detectors, professional manufacturing, and the ideal choice for vehicles.
• Easy to install ------ installation is very simple. It does not require complicated tools, which can be used convenient and Save your time, don't need frequent replacement, but it is recommended to install

How to Use: The installation height should be greater than 20cm/7.87in, and the installation distance should not be less than 2m/6.56ft. When installing, release the OFF light on the machine, then fix it, connect the line, and the installation is complete. Specification: Item Type: Infrared Beam Sensor Material: ABS + Metal Receiver Parameters: ≤15m/49.2ft, when there is severe weather such as heavy rain or fog, the distance will be shortened by 30%. Infrared Emission Frequency: 1.92Khz Input Power: DC or AC 12-24V Wavelength: 940nm Input Current. RX 15mA-TX 30mA Working Environment: -10℃-70℃ Maximum Load: 36V Active Infrared Radiation Detector Dimensions: Approx. 100x35x40mm/3.94x1.38x1.57in Application: Vehicle gate system, access control system, security alarm system Package List: 2 x Alarm 6 x Screw 6 x Screw Sleeve 1 x Manual
