Oumefar DC18-48V DM542 Stepper Motor Driver 57/86 Series 2-phase Stepping Motor Driver

• 【STEPPER MOTOR DRIVER】: The Motor Driver can drive 4-wire / 8-wire two-phase stepper motor, with high quality assurance, hope can meet your demand.
• 【STABLE RUNNING DRIVER】: This Stepper Motor Driver can maintain stable running and low noise under medium-low speed, which can bring you good using experience.
• 【PRECISE CURRENT CONTROL】: This Stepper Motor Driver has precise current control, which greatly reduces the motor heat, and you don’t have to worry about the working performance of this Motor Driver.
• 【ANTI-INTERFERENCE DRIVER】: The Motor Driver inputs optical isolation signal, with strong anti-interference ability, and will bring you good using experience.
• 【SELF-TUNING FUNCTION】: The Stepper Motor Driver has integrated with parameter self-tuning function, which can automatically generate optimal operating parameters for different motors.

The DM542 digital stepper motor driver adopts the latest 32-bit DSP technology, suitable for driving 57 and 86 series motors. It has excellent medium-low speed performance and can meet the application needs of most medium and small equipment. Features: 1. Integrated with parameter self-tuning function, which can automatically generate optimal operating parameters for different motors. 2. Can drive 4-wire / 8-wire two-phase stepper motor. 3. Stable running and low noise under medium-low speed. 4. Precise current control greatly reduces the motor heat. 5. Optical isolation signal input, strong anti-interference ability. 6. With over-voltage, over-current protection. Specification: Model: DM542 Input voltage: 18-48VDC, 36V(Typical) Output current: 1.0-4.2A Pulse response frequency: 200kHz(Max) Insulation resistance: ≥500MΩ Subdivision range: 400~25600ppr Weight: Approx. 268g / 9.4oz Package list: 1 * Steeper Motor Driver
