Optimum 24 Hour Time Switch, White, One Size

• 24 hour single channel quartz time switch with 15 minute tappet intervals and a 150 hour running reserve
• Designed for surface, flush & din-rail mounting
• 16 amp resistive; 8 amp inductive
• Incandescent lamp load of 1300W
• Volt free SPDT contacts; Not suitable for discharge or LED lighting without a contactor

OP-TS211.1 is a quartz general purpose time switch designed for mounting on a surface, panel or DIN-Rail. It is programmable for 24 hour operation with a minimum captive tappet switching setting of 15 minutes. The unit can be run on Fixed On / Timed / Fixed Off selections with the accuracy being mains synchronised (typically +/- 2.5 seconds per day). There is an inbuilt re-chargeable battery cell to keep the timer running in the event of loss of power, this cell will run for 48 hours. This timer controls a volt-free changeover switch and has a resistive rating of 16 Amperes. It comes with 5 x wire-protect screw terminals. Without a contactor fitted, this timer is not suitable for discharge or LED lighting. Dimensions of the timer are: 106mm (h) x 72mm (w) 52mm (d), and the weight is 266g.
