LGIDTECH DMX512 LED Light Bulb Miboxer 9W E27 RGB+CCT Color Changing and Color Temperature Adjustable, Work with DMX512 Console Panel Via Milight DMX512 Transmitter (Sold Separately)

• 1)Set the Address:1. Hold "SET" until dXXX blinks. 2. Choose the address by pressing + or -, there are totally 512 addresses. 3. After choosing the address, hold "SET" until dXXX stops blinking.
• 2)Link: Choose the zone for the DMX light bulb first by pressing + or -, e.g. "CH12" means zone 12. Turn off the DMX light bulb, turn on again,after bulb lights up,press SET three times within 3 seconds, the light bulb blinks slowly three times with green color, now the light bulb is linked in zone 12, there are totally 16 zones.
• 3)UNLINK: Turn off the DMX light bulb, turn on again, within 3 seconds press SET five times, the light bulb blinks quickly 10 times with red color, now the unlink is done.
• 4)To adjust the first channel of any light under any zone(CHXX) or any address (dXXX), there are two steps to follow, first choose this light bulb, then find out the red color channel, you can get it from the this formula: [ dXXX+(CHXX-1)*5 ]/16 = Q
• 5)When the result Q is not a whole number, and the reminder is E, then press Q+1 under Scanner and choose this light bulb, then the red is the E channel, green is the E+1 channel, blue is the E+2 channel, warm white is the E+3 channel, cool white is the E+4 channel.

Product Name: DMX512 9W RGB+CCT LED Bulb Sold by brand: LGIDTECH Power: 9W Voltage: AC 100~240V 50/60Hz Color Temp.: 2700K~6500K Luminous Flux: 960lm Luminous Efficiency: 107lm/W CRI: >80 PF: >0.5 Base Type: E27 Beam Angle: 220° RF: 2.4GHz Control Distance: 30meters=98ft Size: Φ74*137mm
