ePathChina Universal 12V Car Auto Remote Central Kit Door Lock Locking Vehicle Keyless Entry System with Remote Control Car Alarm System

• 【Remotely Lock and Unlock】 LOCK: Press the"Lock" button of remote once, parking light will flash once, siren sounds once, central door lock automatically. LED indicator flash once per second. (Default no siren no sound); UNLOCK: Press the "Unlock"button of remote, parking light will flash twice, siren sounds twice, central door unlock automati-cally, LED indicator will be closed.
• 【Car Search & Electronic Door Lock/Pneumatic Door Lock】 The main unit default electronic lock; Press"Bell"button of remote once, parking light will flash 30s, the siren sounds, press the same button again will stop; If no this button press lock button many times.
• 【Code Learning & Clear Code】 Press learning switch once, turning light flash once, after press remote any button, the code was learned, if need to learn more remote ,repeat it again; Press the learning switch 3 seconds turning light flash 3 time it was cleared.
• 【Power Window Output (-25s)】 Press" Lock " button once, turning lights flash once and door lock, now the power window signal output negative trigger 25s ,the function depend on the car circuit delay.
• 【Trunk Release(-3s,50mA)】Press the button "Unlock/ Trunk /Mute" on the remote transmitter 3 seconds to release the trunk while the parking lights will flash three times. it assisted by an actuator & a relay.

Features: - Remotely lock and unlock your car. - Direction light flashing. - LED indicator. - Remote car location. - Remote trunk release. - Rising power window. Turning Light: 7.5 A x 2 Static Current: 8.5 mA Working Frequency: 433.92MHz Working Voltage: DC 12 +/- 3V Central Locking: 10A Type Of Remote Control: Without LCD Remote Control Type: Anti-Theft Device One-Way Type Of Accessory: Alarm Key Mold Remote Controlled: Yes Feature: Remote Central Lock Product Weight: 209 G / 7.37 Ounces Product Dimensions (L*W*H) : 120*80*60 MM / 4.72*3.15*2.36 Inches Package Weight: 209.0 G / 7.37 Ounces Package Dimensions(L*W*H): 124*90*75 MM / 4.88*3.54*2.95 Inches Installation: - The car burglar alarms need installed by the professionals with car electrician certificated. - For 12V DC car which have central door lock. The item without actuator of central door lock. - Place of Application: 12V Car Note: - NO mute and locate function. - (IMPORTANT) Professional Installation Is Highly Recommended. - Please check the size measurement chart carefully before making payment. - The color of the actual items may slightly different from the listing images due to different computer screen. Package Include: 1 x Main Control Unit 2 x Remote Control 1 x Wiring Set 1 x LED Indicator 1 x English User Manual
